Design and description
18 02.00 | PGL-plus-P | Assembly- and Operating Manual | en | 1508050
4 Design and description
4.1 Design
2-Finger Parallel Gripper
1 Housing
2 Base jaw
3 Compressed air main connection
4 Air purge connection
5 Groove for magnetic switch
