SCHUNK PGL-plus-P - Switch-Off Hysteresis for Magnetic Switches

Assembly and settings
5.5.3 Switch-off hysteresis for magnetic switches
Sensors MMS 22-PI1, MMS 22-PI2:
The smallest detectable stroke difference is shown in the following
table:
Minimum detectable stroke difference from nominal stroke
For products with Xmm
nominal stroke per jaw
Min. monitoring area per jaw/
min. stroke difference to be
monitored per jaw
X ≤ 5 mm 30% of the nominal stroke per jaw
X > 5 mm to X ≤ 10 mm 20% of the nominal stroke per jaw
X > 10 mm 10% of the nominal stroke per jaw
Example: Product with 7mm nominal stroke per jaw
7mm * 20% = 1.4mm
3302.00 | PGL-plus-P | Assembly- and Operating Manual | en | 1508050
