7.6 Tightening torques
Position of the item numbers: }7.7 [
/
57]
Tightening torque for screws – details in Nm
Size Item
13
Item
115
Item
116
Item
117
Item
118
Item
119
Item
120,
128,
129
PGL-plus-P 10 9 0.53 0.27 2.1 2.1 0.06 0.53
PGL-plus-P 13 15 0.94 0.53 2.1 2.1 0.11 0.94
PGL-plus-P 16 37 2.2 0.94 5.3 5.3 0.21 2.2
PGL-plus-P 20 72 4.3 2.2 11 11 0.21 4.3
PGL-plus-P 25 120 4.3 2.2 18 18 0.45 7.3
