Assembly and settings
Item Mounting PGL-plus-P
10 13 16 20 25
Side C
5 Mounting screw M4 M4 M5 M6 M8
Mounting screw according
to standard
DIN EN ISO 4762
Max. strength class 8.8
4 Centering sleeve Ø 6 Ø 6 Ø 8 Ø 10 Ø 12
Side D
6 Mounting screw M5 M5 M6 M8 M10
Max. depth of engagement
from locating surface [mm]
10 12 15 17 20
4 Centering sleeve Ø 6 Ø 6 Ø 8 Ø 10 Ø 12
5.3.2 Pneumatic connection
NOTE
• Observe the requirements for the compressed air
supply, }3 [
/
16].
• In case of compressed air loss (cutting off the energy line), the
components lose their dynamic effects and do not remain in a
secure position. However, the use of a SDV-P pressure
maintenance valve is recommended in this case in order to
maintain the dynamic effect for some time. Product variants
are also offered with mechanical gripping force via springs,
which also ensure a minimum clamping force in the event of a
pressure drop.
2502.00 | PGL-plus-P | Assembly- and Operating Manual | en | 1508050
