6. Cover Assembly
STATIM 5000/5000S/5000 G4 Service Guide
Removing and Replacing the LCD
To remove the LCD (1) from the fascia (2), proceed as follows (see Figure 4):
1. If present, remove the printer module (3). See section 12. Printer, Removing the Printer Module.
2. Carefully remove the membrane keyboard (4) from the fascia. See Membrane Keypad Removal
and Replacement, above.
3. Using a Phillips screw driver remove and retain the four countersink screws (5) securing the LCD
to the fascia. Each screw is held by a captive fastener (6) which is integral to the LCD assembly.
4. The keypad cable (7) and the LCD cable (8) are secured together with double sided adhesive
tape. Carefully separate the harnesses and remove the LCD.
To replace the LCD (1), follow these steps (see Figure 3):
1. Align the captive fasteners (6) on the LCD with the four clearance holes in the fascia (2) and
reinstall the LCD using the four countersink screws (5) retained from disassembly. The LCD
cable (8) and the keypad cable (7) are on the same side of the cover.
Note: Do not press down in the middle of the LCD assembly. Apply pressure in the areas
immediately adjacent the mounting holes only.
2. Carefully reinstall the membrane keyboard (4) on the fascia. See Membrane Keypad Removal
and Replacement, above.
3. If present, reinstall the printer module (3). See section 12. Printer, Replacing the Printer Module.
4. Secure the cables together using double sided adhesive tape.
5. Connect the keypad connector to Controller Board (9) P4.
6. Connect the LCD connector to Controller Board P3.
7. Connect the printer connector (if present) to controller board P2 or pressure interface board (10)
connector P2, if present.
8. Power the unit ON. If the LCD fails to display the “select a cycle” message, the microprocessor
is improperly installed or the LCD intensity pot is not adjusted correctly. If the amber LED on
the front cover is flashing, or the solenoid valve is activating repeatedly, the LCD connector is
incorrectly installed.
9. If the LCD intensity or contrast is not suitable, adjust the pot labeled either DIS or DISP, on the
controller board.
10. Reinstall the cover. See Cover Removal and Replacement, above.
