12. Printer and Data Logger
STATIM 5000/5000S/5000 G4 Service Guide
3. Insert the MSD in the relevant port on the computer and wait until the computer has recognised
the new device (if transferring for the first time).
4. The contents of the MSD should now be available for viewing in the appropriate application (e.g.
Windows Explorer).
5. Locate, or create the preferred folder for storing the data.
6. Data can now be transferred by either:
a. Drag and Drop
b. Cut and Paste
c. Copy and Paste (if you wish to retain the data on the MSD)
7. Safely ‘eject’ the MSD as appropriate to your computer and remove the MSD.
8. Re-insert the MSD back in to the Data Logger.
9. After a few seconds the STATim LCD display should now show the following:
10. The STATim and Data Logger are now ready for use.
Data Logger Specifications
Connection: Serial Cable DB9F-DB25M
Baud Rate: 9600
Electrical Rating: 100V-240V, 0.6A, 50/60 Hz, multiplug
ACKNOWLEDGED MSD
USB Flash Drives:
Cruzer mini 1 GB
Memorex Travel drive 1 GB
Kingston Travel drive 512 MB
PNY Attache 1 GB
Lexar Jump Drive 1 GB
SD Memory Cards:
Kingston 512 MB
Lexar 512 MB
PNY 512 MB
Ultra 512 MB
Kingston ultimate 512 MB
Other USB Flash Drives and SD Cards may also be compatible with this Data Logger.
HH:MM DD/MM/YYYY
“MSD NOTDETECTED”/”INSERT
MSD/FLASH”/”SELECT A CYCLE”
HH:MM DD/MM/YYYY
USB/FLASH DETECTED/SAFELY
REMOVE MSD/SELECT A CYCLE
