12. Printer and Data Logger
STATIM 5000/5000S/5000 G4 Service Guide
Printer and Data Logger
STATim 5000/5000S units are capable of operating several printing or data recording devices
depending on the model.
The following is an overview of unit variants and what can and cannot be used with them:
1995 – 2007: STATim 5000/5000S units with revision 2.x/5.x or 6.x controller board
 •Thesewereavailablebothwithandwithoutabuilt-inSTATPRINTERmechanismlocated
on the left side of the front fascia.
 •TheinternalprintermechanismisthesameastheSTATPRINTERmechanismusually
associated with the external 2000/2000S STATPRINTER unit.
 •UnitspurchasedWITHOUTaprintercanberetro-ttedwithaprintermoduleusingpart
number 01-210000 “Thermal Internal Printer Kit for STATim 5000/5000S”.
• Note that a SciCan Data Logger cannot be tted to these units as the chassis
cannot accommodate the installation of the appropriate cable port.
2007 onwards: STATim 5000/5000S units with revision 7.x controller board
 •TheseunitsarealsoavailablebothwithandwithoutabuiltinSTATPRINTERmechanism
located on the left side of the front fascia.
 •UnitspurchasedWITHOUTaprinterwillhavea9-pinRS232portlocatedontherearof
the chassis for connecting an external (generic) printer OR a SciCan Data Logger.
 •Theseunitscanalsoberetro-ttedwithaprintermoduleusingpartnumber01-210000
Thermal Internal Printer Kit for STATim 5000/5000S.
 •UnitsWITHaninternalprinterDONOThavea9-pinRS232portontherearofthe
chassis but DO have a cutout in the chassis to retro-fit a port using part number 01-
110222S “RS232 Port Kit, STATim 5000/5000S” should you wish to convert a printer
unit to a Data Logger unit.
General notes:
For revision 2.x/5.x/6.x controller boards
 •Theprintercableconnectoron5000nonSunitsisattachedtotheP2 connector on the
main PCB.
 •Theprintercableconnectoron5000SunitsisattachedtotheP2 connector on the
pressure interface PCB.
For revision 7.x controller boards
 •TheprintercableconnectororRS232internalportconnectoronALL5000/5000Sunits
is attached to the SERIAL connector on the main PCB.
For all units
 •Someinternalprintermoduleassembliesweremanufacturedwithaferritecore
assembled to the cable. If so, ensure the ferrite core is in place when the assembly is
reinstalled. See; “Positioning the Ferrite Core”.
