STAT IM 2000/2000S Service Guide
96-106775 Rev 5.0
4. STAT IM 5000 Calibration
1. Control box
2. Controller board
3. SELECT knob
4. Digital voltmeter
5. Calibration cassette
6. Thermocouple
7. Digital thermometer
Figure 3
1
2
3
4
5
6
7
NOTE: The cover MAY be removed and the control box attached if deemed appropriate, but the
unit can be calibrated with the cover on as all adjustments to the calibration offsets are undertaken
using the keypad on the unit.
STATIM 5000/5000S/5000 G4 Service Guide
