Section 11 STEERING SYSTEM
Subsection 02 (STEERING SYSTEM)
SMR2000-069_11_02A.FM 11-02-1
STEERING SYSTEM 0
RX and RX DI Models
F16K01S
1
2
3
23
21
5
6
5
6
22
7 Nm
(62 lbfin)
26 Nm
(19 lbfft)
Synthetic
grease
12
11
6 Nm
(53 lbfin)
Loctite
243
25 Nm
(22 lbfin)
19
25
10 Nm
(89 lbfin)
26
20
25 Nm (22 lbfin)
3 Nm (26 lbfin)
6 Nm (53 lbfin) 17
Loctite
243
15
16
18
9
6 Nm (53 lbfin)
Loctite
243
10
8
14
Loctite
243
14 Nm
(10 lbfft)
13
7
4
4 Nm
(35 lbfin)
10 Nm
(89 lbfin)
Loctite 243
4
