SeaSTAR OPTIMUM EPS - Page 67

© 2014 SeaStar Solutions Optimus Installation Manual, Rev. E
5-25
If additional harness length is required to reach the SmartCylinder,
extension harness are available (see Section 4.3.5).
Connect the SmartCylinder harness to the PCM (as shown on
page 5-27).
FAILURE TO SECURE HARNESS MAY RESULT IN HARNESS WEAR,
CAUSING LOSS OF STEERING CONTROL, PROPERTY DAMAGE,
PERSONAL INJURY AND OR DEATH.
Port Cable Installation (alternate method)
Figure 5-26.
WARNING
