Seiki VS50 - Page 8

1 - 3
Program
START / FEED
HOLD switches
Axis move
switches
Initial position
check
Status display
lamp
[5]
[6]
[7]
[8]
Operation method
Push
button
Lamp
Effective mode
Auto. Manual
Use
Name
Group
No.
FEED HOLD.. This push button
switch suspends a program’s
progress. An axis being operated
stops and a red lamp located above
lights up. During operation by an
auxiliary command (M, S or T), the
program’s progress stops after
executing the remaining action of
respective command.
These push button switches move
the X, Y, Z and A (optional) axes
respectively.
Axis selection and its moving
direction abide by the indication
given on the respective push button
switches.
For a feed rate, select among the
FEEDRATE switches [22].
When executing rapid traverse, push
the rapid traverse button at the some
time.
APC INITIAL POSITION... This lamp
indicates that each machine section
is located at its specified position,
when executing an automatic. pallet
change (APC) command.
ATC INITIAL POSITION... This lamp
indicates that each machine section
is located at its specified position,
when executing an automatic tool
change (ATC) command. During T
cycle operates, this lamp lights up.
ALARM ... A red lamp lights up when
an alarm occurred.
PROGRAM STOP... When M00 or
M01 is executed during operation in
an automatic mode, a red lamp lights
up. It is lit off by starting or
continuing the program.
O
O
O
O
O
O
O
O
O
O
O
O
O
O
