1 - 4
Automatic
power shut-off
switch
Call right off
switch
Work setter
Safety check
Operation method
Push
button
Lamp
Effective mode
Auto. Manual
Use
Name
Group
No.
[9]
[10]
[11]
[12]
This makes the automatic power
shut-off function effective. After
machining cycle is completed, the
power is automatically shut-off by
M30 when no pallet exists.
This switches off the lighting call
light (yellow lamp melody horning.
Makes the following functions
effective, making use of a reference
touch tool
TOOL SETTER... Measures a tool
length and a tool diameter and
automatically sets their offset
amounts in the offset memory.
REF. SURFACE, REF. HOLE ...
Measures the coordinate system
shift amounts of the reference
surface and hole against the
machine coordinate system and
sets them in the coordinate system
shift memory.
COORD ALIGN... By measuring 3
points on the orthogonal or jig
located on the X-Y plane,
differences in rotation angle with the
X and Y axes are calculated and
stored, thus compensating X-axis
and Y-axis program coordinate
values.
Measure a machining tool length by
the 1st program start. Measure the
workpiece at an actual machining
position with the reference touch
tool mounted to the spindle by the
2nd program start. A workpiece-tool
interference check is made by Z-
axis approach (G00) command,
adding the tool offset amounts used
for these two information.
O
O
O
O
O
O
O
O
O
O
OO
O
O
O
