SEW-Eurodrive MOVIFIT basic - Mechanical Installation; 4.1 Installation instructions

Operating Instructions – MOVIFIT® basic
13
4
Installation instructions
Mechanical installation
4 Mechanical installation
4.1 Installation instructions
4.1.1 General information
Note the following when installing the MOVIFIT
®
basic unit:
• Observe the general safety notes.
• Only install the MOVIFIT
®
basic unit on a level, low-vibration, and torsionally rigid
support structure.
• Ensure sufficient clearance around the unit to allow for adequate cooling. Warm
outlet air of other units must not be drawn in.
• Strictly observe all instructions as to the technical data and the permissible condi-
tions regarding the place of installation.
• Do only use provided attachment options when mounting the drive.
• Cover the unused plug connectors with blind caps.
The degree of protection specified in the technical data only applies for a correctly
installed MOVIFIT
®
basic unit.
4.1.2 Installation requirements
Make sure that the following requirements are met before you start installing the unit:
• The nameplate data of the MOVIFIT
®
basic unit match the voltage supply system
• The MOVIFIT
®
basic unit is undamaged (no damage caused by transportation or
storage).
• The ambient temperature corresponds to the specifications in chapter "Technical
Data".
• The MOVIFIT
®
basic unit must not be installed under the following harmful ambient
conditions:
– Potentially explosive atmospheres
– Oils
–Acids
– Gases
– Vapors
– Radiation
–etc.
NOTICE
Loss of warranted degree of protection if the MOVIFIT
®
basic inverter is installed
incorrectly or not at all.
Damage to the MOVIFIT
®
basic unit.
• If you remove the EBOX from the ABOX, you have to protect the EBOX and the
ABOX from moisture and dust.
