Operating Instructions – MOVIFIT® basic
5
Topology
Electrical installation
5.2 Topology
The following figure shows a typical MOVIFIT
®
basic drive system with AS-Interface
control:
The table shows typical characteristics at an ambient temperature of 40 °C with routing
type B2 according to EN 60204-1.
The applicable country-specific standards and regulations must also be observed for in-
dividual project planning and installation.
9007201945761931
K: Line contactor
Circuit breaker for
line protection
Power bus (line cable) Motor cable
Type Minimum con-
ductor
cross section
Maximum
total length
Minimum
conductor
cross section
Maximum
length
[1] [2] [3] [4] [5]
B16 2.5 mm
2
AWG14
130 m
1.5 mm
2
AWG16
3m
B16 2.5 mm
2
AWG14
130 m
2.5 mm
2
AWG14
10 m
B20 4.0 mm
2
AWG12
170 m
2.5 mm
2
AWG14
3m
B25 6.0 mm
2
AWG10
190 m
2.5 mm
2
AWG14
3m
[4]
[5]
[4]
[5]
[1]
K
A
C 3 x
380 - 480 V
[2] [3]
