Operating Instructions – MOVIFIT® basic
9
MOVIFIT
®
basic with binary control
Technical data
9.3 MOVIFIT
®
basic with binary control
MOVIFIT
®
basic type MBF07A-B1-A1 MBF15A-B1-A1 MBS4DA-B1-A1 MBS4RA-B1-A1
Part number 1 825 247 8 1 825 249 4 1 825 253 2 1 825 251 6
Inverter
Dual motor
starter
Reversing
starter
Apparent output power at
V
line
= AC 380 – 480 V
S
N
1.8 kVA 2.8 kVA 6.9 kVA 6.9 kVA
Supply voltages
Permitted range
V
line
AC 3 x 380 V –10 % – AC 480 V +10 %
Line frequency f
line
50 – 60 Hz ±10 %
Nominal line current
(with V
line
= AC 400 V)
I
line
AC 2.9 A AC 5.4 A AC 10 A AC 10 A
Output voltage V
O
0 – V
line
V
line
Output is not short-circuit proof Output is not short-circuit proof
Output frequency
Resolution
Operating point
f
O
2 – 120 Hz
0.01 Hz
400 V at 50 Hz
f
line
–
–
Rated output current I
N
AC 2.2 A AC 4.1 A AC 2 x 5.0 A AC 10.0 A
Motor power S1
P
Mot
0.75 kW
1.0 HP
1.5 kW
2.0 HP
2 x 2.2 kW
2 x 3.0 HP
4.0 kW
5.4 HP
PWM frequency 4 (factory setting)/8/16 kHz –
Current limitation
(Output is not short-cir-
cuit proof)
I
max
Motor: 150%, 60 s
Regenerative: 150%, 2 s
None
Maximum motor cable
length
3 m unshielded
10 m shielded
10 m unshielded
Interference immunity Meets EN 61800-3
Interference emission Meets category C3 according to EN 61800-3
Ambient temperature ϑ
A
-10 – +40 °C
P
N
reduction: 3 % I
N
per K up to 60 °C
Climate class EN 60721-3-3, class 3K3
Storage temperature
1)
–30 to +85 °C (EN 60721-3-3, class 3K3)
Maximum permitted
vibration and shock load
According to EN 50178
Degree of protection IP54 (MOVIFIT
®
basic housing closed and all plug connections sealed).
Duty type S1 (EN 60149-1-1 and 1-3)
Cooling type (DIN 41751) Self-cooling
Installation altitude h ≤ 1000 m: no reduction
h > 1000 m: I
N
reduction by 1% per 100 m
h > 2000 m: V
line
reduction by AC 6 V per 100 m,
Overvoltage class 2 according to DIN 0110-1
h
max
= 4000 m
Also see chapter "Installation altitudes above 1000 m amsl" in the operating
instructions
Mass 3.3 kg 3.0 kg 2.7 kg
Dimensions W x H x
D
See chapter "Dimension drawings" in the operating instructions
Required preventive mea-
sures
Grounding the unit
P
i
f
