MOVIFIT
®
basic with binary control
Technical data
Brake rectifier BG brake rectifier for SEW brakemotors
Brake voltage = supply voltage V
line
4 digital inputs (X11, X12) Isolated via optocoupler; PLC compatible (EN 61131-2)
R
i
≈ 3.0 kΩ, I
E
≈ 10 mA, sampling cycle ≤ 8ms
Signal level +13 – +30 V
-3 – +5 V
= "1", contact closed
= "0", contact open
Control functions DI0 – DI3, see chapter "Functions of MOVIFIT
®
basic with binary control"
2 digital outputs (X13) PLC-compatible in accordance with EN 61131-2
Signal level +15 V – +30 V
-3 V – +5 V
"1"
"0"
Rated current Max. 20 mA per output / not sustained short circuit proof
Signaling functions DO0 – DO1, see chapter "Functions of MOVIFIT
®
basic with binary control"
DC 24 V output (X13) Interference-voltage-proof and short-circuit-proof
DC 24 V ± 25 %
Max. 100 mA minus the current load at digital outputs DO0+DO1
1) If the unit is stored for a long time, connect it to the supply system voltage for at least 5 minutes every 2 years. Otherwise, the unit's
service life may be reduced.
MOVIFIT
®
basic type MBF07A-B1-A1 MBF15A-B1-A1 MBS4DA-B1-A1 MBS4RA-B1-A1
Part number 1 825 247 8 1 825 249 4 1 825 253 2 1 825 251 6
Inverter
Dual motor
starter
Reversing
starter
