Operating Instructions – MOVIFIT® basic
49
6
Parameter directory of the MOVIFIT
®
basic inverter
Startup
6.8 Parameter directory of the MOVIFIT
®
basic inverter
The following tables show the unit-relevant parameters. The keypad shows additional
parameters that are without function for MOVIFIT
®
basic.
6.8.1 Standard parameters
The following table shows the standard parameters:
No. Name Range Standard Description
P1-01 Upper speed limit
[Hz] or [rpm]
P1-02 – P1-09 x 5
(up to 2000 Hz max.)
50.0 Hz Setting the upper speed limit.
The display in [Hz] or [rpm]
depends on parameter P1-10.
P1-02 Lower speed limit
[Hz] or [rpm]
0 – P1-01 0.0 Hz Setting the lower speed limit.
The display in [Hz] or [rpm]
depends on parameter P1-10.
P1-03 Acceleration ramp 0.0 s – 3000 s 5.0 s Time for acceleration along the
ramp from 0 to the nominal fre-
quency (P1-09).
P1-04 Deceleration ramp 0.0 s – 3000 s 5.0 s Time for deceleration from the nom-
inal frequency (P1-09) to 0.
At P1-04 = "0", the maximum decel-
eration is realized.
P1-06 Energy optimization
(for V/f mode only)
0: Deactivated 0 With P1-06 = "1", the unit reduces
the supplied motor voltage in case
of light loads.
1: Activated
P1-07 Nominal motor voltage 0.2 – 500 V 400 V Set the nominal motor voltage
according to the motor nameplate.
With P1-07 = "0", voltage compen-
sation is deactivated.
P1-08 Nominal motor current 0.4 – 2.2 A (with MBF07A..) 2.2 A Set the nominal motor current
according to the motor nameplate
[A].
0.8 – 4.1 A (with MBF15A..) 4.1 A
P1-09 Nominal motor fre-
quency
25 – 500 Hz 50 Hz Set the nominal motor frequency
according to the motor nameplate
[Hz].
P1-10 Nominal motor speed 0 – 30000 rpm 0 Set the nominal motor speed
With P1-10 ≠ 0, all speed-related
parameters are displayed in rpm.
P1-11 Speed n1 -P1-01 – +P1-01 50 Hz The drive runs with this speed in jog
mode, or when the speed n1 was
selected by the higher-level control-
ler.
P1-12 Control mode of the
drive
0: Binary signals or
AS-Interface
0 Setting the control mode
1: Manual mode
(only clockwise)
2: Manual mode
(CW and CCW opera-
tion)
P1-13 Error log The 4 most recent errors are
logged.
Display of
the most
recent error
The most recent error is displayed
first.
Exception: Undervoltage errors are
only logged once.
00
