SEW-Eurodrive MOVIFIT basic - Manual Operation with MB-LC Keypad

Operating Instructions – MOVIFIT® basic
59
7
Manual operation with MB-LC keypad
Operation
7.4 Manual operation with MB-LC keypad
7.4.1 Activating manual mode
The manual mode can only be activated if:
• the drive has not
been enabled by the higher-level controller
• and parameter P1-12 = "0".
To activate manual mode, press the for at least 2.5 s. The display then shows "L-
0000".
7.4.2 MOVIFIT
®
basic manual mode
In manual mode, you control the drive by setting/resetting control bits DO3 – DO0 via
the – keys.
The display show the current status of control bits DO3 – DO0.
MOVIFIT
®
basic
inverter
The following table shows control bits and the functions of the drive.
MOVIFIT
®
basic
motor starter
The following table shows control bits and the functions of the drive.
0
3
Control bit Function
DO3 DO2 DO1 DO0 MOVIFIT
®
basic inverter
XX00 Stop
X X 0 1 Enable CW
X X 1 0 Enable CCW
X X 1 1 Stop/reset
0 0 X X Setpoint speed = n1
0 1 X X Setpoint speed = n2
1 0 X X Setpoint speed = n3
1 1 X X Setpoint speed = n4
Control bit Function
DO2 DO1 DO0 MOVIFIT
®
basic
Reversing starter
MOVIFIT
®
basic dual motor
starter
0 0 0 Stop Stop
001
Enable CW Enable signal for motor at terminal
X9
010
Enable CCW Enable signal for motor at terminal
X8
011
Stop Enable signal for both motors at X9
+ X8
1 X X Reset Reset
