Operating Instructions – MOVIFIT® basic
19
5
Power bus connection (line cable)
Electrical installation
5.3 Power bus connection (line cable)
Connect the MOVIFIT
®
basic unit to the power bus (line cable) as follows.
1. Loosen the 4 screws and remove the EBOX from the ABOX.
2. Remove the supply system plug connector from the FieldPower
®
contact module.
WARNING
Electric shock due to charged capacitors.
Severe or fatal injuries.
• De-energize the MOVIFIT
®
basic drive using a suitable external cut-off device be-
fore removing the EBOX from the ABOX.
• Secure the drive against unintended re-connection to the voltage supply.
• Then wait at least for 10 minutes.
WARNING
Danger of burns due to hot surfaces of the MOVIFIT
®
basic unit.
Severe injuries.
• Do not touch the MOVIFIT
®
basic until it has cooled down sufficiently.
