Operating Instructions – MOVIFIT® basic
9
Technical data
9.5.2 Dimension drawing of LT-BG / MB-LC operator terminal
65
81
21
3
55
70
55
2689204875
Recess
for control cabinet installation
The operator terminal meets the requirements of IP54 when it is installed correctly.
