C4FM/Fusion® radio setup
Set the radio to single frequency mode.
Use digital narrow (DN) mode. Voice wide (VW) mode does not support late
entry.
If your radio has half deviation mode turned on, make sure you use the
C4FM Half Deviation
modem mode on the openSPOT4.
You can make a test call to the openSPOT4's built-in local echo service to
test the connection between the transceiver and the openSPOT4 by setting
the DGID to 99 in your radio. Don't forget to set the DGID back to AUTO (or
ALL or 00, depending what's available on your radio) after you've done with
the local echo test.
Run AutoCal in case you use the C4FM Half Deviation mode and there are
voice quality issues. See the AutoCal's usage description in the Connectors
section below.
Take a look at the Wires-X® button usage description and the C4FM/Fusion®
APRS® page if you want to forward your transceiver's GPS position to the
APRS® network.
NXDN® radio setup
Set up a simplex channel (with the same RX and TX frequencies).
Set the channel's Radio Access Number (RAN) to the openSPOT4's RAN (by
default it's 0, it can be changed on the Settings page, NXDN® settings
section).
Create a contact with private call to ID 9999, which is the openSPOT4's
built-in local echo service. Make a call to this ID to test the connection
between the transceiver and the openSPOT4.
Run AutoCal in case you have voice quality issues. See the AutoCal's usage
description in the Connectors section below.
P25 radio setup
Set up a simplex channel (with the same RX and TX frequencies).
Set the channel's Network Access Code (NAC) to the openSPOT4's NAC (by
default it's 0, it can be changed on the Settings page, P25 settings section).
Note that the openSPOT4 requires the NAC in decimal format (example:
if you have the NAC 0x293 in your radio then you have to enter 659 in the
openSPOT4).
Create a contact with private call to ID 9999, which is the openSPOT4's
built-in local echo service. Make a call to this ID to test the connection
between the transceiver and the openSPOT4.
Run AutoCal in case you have voice quality issues. See the AutoCal's usage
description in the Connectors section below.
POCSAG pager setup
Make sure you set the your pager's receive frequency to the openSPOT4's
POCSAG frequency, and that the baud rates match. Polarity should be
