MX-M316N SIMULATION 6 – 21
22-43
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
JAM data details display
Section
Operation/Procedure
1) Select the item to be checked with the touch panel key.
When [COUNTER] key is pressed, the JAM counter, the paper
feed counter, and the paper feed retry counter are displayed.
When [HISTORY1] key is pressed, the JAM history is dis-
played. When [HISTORY2] key is pressed, the temperature
and humidity data are displayed.
2)Printable with [START] keys.
Display data and contents (COUNTER)
Display data and contents (HISTORY1)
22-90
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to output the various set data lists.
Section
Operation/Procedure
1) Change the display with scroll key.
2) Select the print target with the keys on the touch panel.
3) Press [EXECUTE] key to start self print of the list.
* When the data list print of system setting is inhibition in DSK
model, this setting is invalid.
Item Content
PAPER JAM COUNT Number of machine JAM troubles
PAPER FEED COUNTER Paper feed counter (Similar with
SIM22-09 display content)
PAPER FEED RETRY COUNTER Paper feed retry counter (Similar
with SIM27-18 display content)
Item Content Description
NO No History number
JAM CODE JAM Code Jam code main
DATE/TIME Date/Time Occurrence date
TOTAL_BW Total Count (BW) Total counter (B/W)
P_S (*1) Paper Size Paper size
P_T (*1) Paper Type Paper type
JOB (*1) Job Mode Job mode
JN Job No First after JOB start or not
OF Offset Paper exit: Offset
EP Exit Position Paper exit: Exit position
PC Punch Paper exit: Punch
SP Staple Paper exit: Staple
All setting list (*) ALL CUSTOM SETTING LIST
Printer test page PCL SYMBOL SET LIST
PCL INTERNAL FONT LIST
PCL EXTENDED FONT LIST
PS FONT LIST
PS KANJI FONT LIST (Japan)
PS EXTENDED FONT LIST
NIC PAGE
Address registration list (*) INDIVIDUAL LIST
GROUP LIST
PROGRAM LIST (Output Disable)
MEMORY BOX LIST
ALL SENDING ADDRESS LIST
Document filing list (*) DOCUMENT FILING FOLDER LIST
System setting list ADMIN. SETTINGS LIST (COPY)
ADMIN. SETTINGS LIST (PRINT)
ADMIN. SETTINGS LIST (IMAGE
SEND)
ADMIN. SETTINGS LIST (DOC FILING)
ADMIN. SETTINGS LIST (SECURITY)
ADMIN. SETTINGS LIST (COMMON)
ALL ADMINISTRATOR SETTINGS LIST
Receive rejection number table ANTI JUNK FAX NUMBER LIST
Receive rejection/allow
address
domain table
ANTI JUNK MAIL/DOMAIN NAME LIST
To E-mail
Transfer table list
INBOUND ROUTING LIST
To administrator Transfer list DOCUMENT ADMIN LIST
Web setting list WEB SETTING LIST
Meta data set list METADATA SET LIST
