Sharp MX-M266N - Page 99

MX-M316N SIMULATION 6 – 20
22-19
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the values of the counters
related to the scan - image send.
Section
Operation/Procedure
Used to display the counter value related to the network scanner
Change the display with scroll key.
22-40
Purpose
Error contents display
Function (Purpose)
Used to display the error code list and the
contents.
Section
Operation/Procedure
1) Select the main error code.
The sub error code and the contents are displayed.
22-41
Purpose
JAM contents display
Function (Purpose)
Used to display the JAM code list and the
contents.
Section
Operation/Procedure
1) Select the main error code.
The sub error code and the contents are displayed.
22-42
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the JAM/trouble data.
Section
Operation/Procedure
1) Select the item to be checked with the touch panel key.
2)Printable with [START] keys.
Item/Display Content
Network
scanner
NET SCN
ORG_B/W
Network scanner document read quantity
counter (B/W scan job)
NET SCN
ORG_CL
Network scanner document read quantity
counter (Color scan job)
Internet
FAX
INTERNET FAX
OUTPUT
Number of internet FAX output
INTERNET FAX
SEND OUTPUT
Number of internet FAX sending page
INTERNET FAX
RECEIVE
Number of internet FAX receive
INTERNET FAX
SEND
Number of internet FAX send
E-Mail MAIL
COUNTER
Number of times of E-MAIL send
FTP FTP COUNTER Number of FTP send
Other SMB SEND Number of SMB send
USB CNT Number of times of USB storage
TRIAL
MODE_B&C
Trial mode counter
(B/W & COLOR scan job)
SCAN TO
HDD_B/W
SCAN TO HDD record quantity (B/W)
SCAN TO
HDD_CL
SCAN TO HDD record quantity
(COLOR)
Display data
Counter Content
Max.
number
of
histories
Remarks
Display Content
JAM CODE/
TROUBLE
CODE
DATE/TIME
TOTAL
COUNT(BW)
PAPER JAM PAPER JAM
COUNT
Number of
machine JAM
troubles
Generated
JAM code
(Machine)
Generated
date/time
(YY/MM/DD
HH:MM:SS)
Total output
quantity of
black and
white
50
The head is the latest, and the bottom is the
oldest. The max. number of histories is 50.
SPF JAM SPF JAM
COUNT
Number of
SPF JAM
troubles
Generated
JAM code
(SPF)
50
When 50 is exceeded, the oldest one is not
displayed sequentially.
TROUBLE TROUBLE
COUNT
Number of
troubles
Generated
trouble code
30
The head is the latest, and the bottom is the
oldest. The max. number of histories is 30.
When 30 is exceeded, the oldest one is not
displayed sequentially.
