MX-M316N SIMULATION 6 – 19
22-13
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the operating time of the
process section (OPC drum, DV unit, toner
cartridge) and the fusing unit
Section
Process
Operation/Procedure
The number of prints and the number of rotations in the process
section are displayed.
22-14
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to display the use status of the toner
cartridge.
Section
Process
Operation/Procedure
The status of the toner cartridge is displayed.
*1: The sum total of LARGE/SMALL is displayed. For the remaining amount, it is common to LARGE/SMALL.
*2: The remaining amount is not displayed.
22-18
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to display the user data delete history.
Section
Operation/Procedure
The date and time of the user data delete are displayed.
Item/Display Content Counter RPM
Number of
use days
Life meter
(Unit: +/-1%)
Number of
remaining
days
MAINTENANCE ALL Maintenance counter (Total) Max. 8 Not displayed 0 - 999 0 - 100(%) 0 - 365
FUSING ROLLER Fusing roller Max. 8 Max. 8 0 - 999 0 - 100(%) 0 - 365
PRESSURE ROLLER Pressure roller Max. 8 Max. 8 0 - 999 0 - 100(%) 0 - 365
SEPARATE PAWL(U) Upper separate pawl Max. 8 Max. 8 0 - 999 0 - 100(%) 0 - 365
CLEANING FELT Cleaning felt Max. 8 Max. 8 0 - 999 0 - 100(%) 0 - 365
TC UNIT Transfer unit Max. 8 Max. 8 0 - 999 0 - 100(%) 0 - 365
OZONE FILTER Ozone filter Max. 8 Not displayed 0 - 999 0 - 100(%) 0 - 365
DEVE CTRG(K) Developer cartridge K Max. 8 Max. 8 0 - 999 0 - 100(%) 0 - 365
DRUM CTRG(K) Drum cartridge K Max. 8 Max. 8 0 - 999 0 - 100(%) 0 - 365
MAIN CHARGER(K) Main charger K Max. 8 Max. 8 0 - 999 0 - 100(%) 0 - 365
DRUM BLADE(K) Drum blade K Max. 8 Max. 8 0 - 999 0 - 100(%) 0 - 365
TONER CTRG(K) Toner cartridge K Max. 8 Max. 8 0 - 999 0 - 100(%) Not displayed
Display item Content
Accumulated No. of
installed cartridges (Unit)
Accumulated No. of near
near end (Unit)
Accumulated No. of
end (Unit)
Remaining quantity
(Unit: %)
INSTALL NN END END RESIDUAL
TONER (K)*
1
Toner number counter (K) 0 - 510 0 - 510 0 - 510 0-25%
25-50%
50-75%
75-100%
LARGE*
2
Toner number counter
(K LARGE)
0 - 255 0 - 255 0 - 255
SMALL*
2
Toner number counter
(K SMALL)
Display item
Content
Item name Date
START Year/month/day/hour/min. Delete history (Date and time
of operation start)
END Year/month/day/hour/min. Delete history (Date and time
of operation end)
