MX-M316N SIMULATION 6 – 18
22-10
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the system configuration
(option, internal hardware).
Section
Operation/Procedure
The system configuration is displayed.
(The model names of the installed devices and options are dis-
played.)
(*) Displayed only in the OSA models.
22-11
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the use frequency (send/
receive) of FAX.
(Only when FAX is installed)
Section
FAX
Operation/Procedure
The values of the FAX send counter and the FAX receive counter
are displayed.
22-12
Purpose
Adjustment/Setting/Operation data check
Function (Purpose)
Used to check the RSPF misfeed positions
and the number of misfeed at each posi-
tion. (When the number of misfeed is con-
siderably great, it can be judged as
necessary for repair.)
Section
RSPF
Operation/Procedure
The paper jam and misfeed history is displayed from the latest one
up to 50 items. (The old ones are deleted sequentially.)
MACHINE MX-M266N Main unit
MX-M316N
MX-M356N
MX-M356U
MX-M265N
MX-M315N
MX-M265U
MX-M315U
MX-M3158N
MX-M2658N
MX-M3158U
MX-M2658U
RSPF MX-RP19 Reversing single pass feeder
MX-RP20
STANDARD
STAMP AR-SU1 Finish stamp
DESK MX-CS12 1-Paper Tray 2nd Drawer
1-Paper Tray 4th Drawer
MX-CS13 1-Paper Tray 3rd Drawer
FINISHER MX-FN26 Inner finisher
MX-TR18/
STANDARD
Job separator
FAX1 MX-FX11 Facsimile expansion kit
NETWORK
SCANNER
MX-NSX1 /
STANDARD
Network Scanner Expansion Kit
PRINTER MX-PB16 Printer expansion kit (PCL)
STANDARD
PS MX-PK11 PS expansion kit
SECURITY MX-FR48U Data security kit (commercial version)
AIM MX-AMX1 Application integration module
SDRAM (ICU) *****MB SDRAM capacity
HDD *****MB Hard disk capacity
SD *****MB SD Card capacity
NIC STANDARD NIC
BARCODE MX-PF10 Bar code font
INTERNET-FAX MX-FWX1 Internet Fax expansion kit
ACM(*) MX-AMX2 Application communication module
EAM(*) MX-AMX3 External account module
AP - Air Purifier
RIGHT TRAY MX-TE10 Paper exit tray unit
FAX OUTPUT FAX print quantity counter (for line 1)
FAX SEND FAX send counter
FAX RECEIVED FAX receive counter
SEND IMAGES FAX send quantity counter (for line 1)
SEND TIME FAX send time
RECEIVED TIME FAX receive time
1
: ‘15/Aug.
1
