MX-M316N SIMULATION 6 – 38
41-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the docu-
ment size sensor and the control circuit.
Section
Operation/Procedure
The detection output level (A/D value) of OCSW and the document
sensor (PD1 - PD7) is displayed in real time.
The light receiving range of PD1 - PD7 is 1 - 255. (Default: 128)
43
43-1
Purpose
Setting
Function (Purpose)
Used to set the fusing temperature in each
mode.
Section
Operation/Procedure
1) Select an item to be set with scroll keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
Item/Display Content Detection level range
OCSW Original cover SW 0-1 ("1" to Close)
PD1 Document detection 1 0 - 255
PD2 Document detection 2 0 - 255
PD3 Document detection 3 0 - 255
PD4 Document detection 4 0 - 255
PD5 Document detection 5 0 - 255
PD6 Document detection 6 0 - 255
PD7 Document detection 7 0 - 255
Item/Display Content
Setting
range
Default value
26cpm 31cpm 35cpm
Group A Group B Group A Group B Group A Group B
SW-
A
SW-
B
SW-
A
SW-
B
SW-
A
SW-
B
SW-
A
SW-
B
SW-
A
SW-
B
SW-
A
SW-
B
A HL_UM READY Ready standby TH_UM set
value
70 - 220
185 185 190 190 185 185 190 190 195 195 195 195
B HL_US READY Ready standby TH_US set
value
70 - 220
180 180 200 200 180 180 200 200 195 195 195 195
C HL_UM PLAIN
PAPER BW
Black-White plain paper
TH_UM set value
70 - 220
190 195 195 200 190 195 195 200 195 200 195 200
DHL_US PLAIN
PAPER BW
Black-White plain paper
TH_US set value
70 - 220
190 195 195 200 190 195 195 200 195 200 195 200
E WARMUP FUMON
HL_UM T
Fusing motor pre-rotation start
TH_US set value
0 - 200
150 150 150 150 150 150 150 150 150 150 150 150
F WARMUP FUMOFF
HL_UM T
Fusing motor previous rotation
complete time
0 - 60
0 0 0 0 0 0 0 0 0 0 0 0
G WARMUP END
TIME
Warm-up complete time 0 - 20
18 18 18 18 18 18 18 18 18 18 18 18
HHL_UM THIN
PAPER
Thin paper TH_UM set value 70 - 220
190 195 190 195 185 185
IHL_US THIN
PAPER
Thin paper TH_US set value 70 - 220
190 195 190 195 185 185
JHL_UM HEAVY
PAPER
Heavy paper TH_UM set value 70 - 220
200 200 200 200 200 200 200 200 200 200 200 200
K HL_US HEAVY
PAPER
Heavy paper TH_US set value 70 - 220
200 200 200 200 200 200 200 200 200 200 200 200
L HL_UM LABEL
PAPER
Label paper TH_UM set value 70 - 220
200 200 200 200 200 200
M HL_US LABEL
PAPER
Label paper TH_US set value 70 - 220
200 200 200 200 200 200
NHL_UM OHP
PAPER
OHP-TH_UM set value 70 - 220
190 195 190 195 195 195
