MX-M316N ADJUSTMENTS AND SETTINGS 5 – 5
2) Select an item to be checked.
3) Enter the developing bias values of items A/B under TS_OFF/
ON.
When [OK] key is pressed, the set value is saved.
When [EXECUTE] key is pressed, the voltage entered in the
procedure 3) is outputted for 30sec.
When [EXECUTE] key is pressed again, the output is stopped.
Stop it in a short time to affect the drum surface. (less than five
seconds)
2-C Transfer current adjustment
This adjustment must be performed in the following cases:
* When the TC high voltage PWB is replaced.
* U2 trouble has occurred.
* The PCU PWB has been replaced.
* The EEPROM of the PCU PWB has been replaced.
1) Enter the SIM 8-6 mode.
2) Select an item to be adjusted.
Butt
on
Item Display Content
Setting
range
Default value
26 31 35
TS_
OFF
ACOPY
DVB
Developing bias
set value in a
copy job (Toner
save mode
OFF)
0 - 650
400 400 430
B PRINTER
FAX
DVB
Developing bias
set value in a
Print/FAX job
(Toner save
mode OFF)
0 - 650
400 400 430
TS_
ON
ACOPY
DVB
Developing bias
set value in a
copy job (Toner
save mode ON)
0 - 650
320 320 320
B PRINTER
DVB
Developing bias
set value in a
print job (Toner
save mode ON)
0 - 650
250 250 250
6,08/$7,21 12
&/26(
7(67
7+96(77,1*$1'287387


$˖
˷˹
˖ 7&3/$,163;:
$˖ 
˖ 7&3/$,1'3;:
%˖ 
˖ 7&3/$,163;1
&˖ 
˖ 7&3/$,1'3;1
'˖ 
˖ 7&3/$,1'3;1
)˖ 
˖ 7&3/$,163;1
(˖ 
˖ 7&+($9<:
*˖ 
˖ 7&+($9<1
+˖ 
˖ 7&+($9<1
,˖ 
˖ 7&2+3:
-˖ 
˖ 7&2+31
.˖ 
˖ 7&2+31
/˖ 
2.
(;(&87(
6,08/$7,21 12
&/26(
7(67
7+96(77,1*$1'287387


$˖
˷˹
˖ 7&3/$,163;:
$˖ 
˖ 7&3/$,1'3;:
%˖ 
˖ 7&3/$,163;1
&˖ 
˖ 7&3/$,1'3;1
'˖ 
˖ 7&3/$,1'3;1
)˖ 
˖ 7&3/$,163;1
(˖ 
˖ 7&+($9<:
*˖ 
˖ 7&+($9<1
+˖ 
˖ 7&+($9<1
,˖ 
˖ 7&2+3:
-˖ 
˖ 7&2+31
.˖ 
˖ 7&2+31
/˖ 
2.
(;(&87(
EXECUTE
EXECUTE
or after 30 sec.
10-key
Item/Display Content
Setting
range
Default value
26 31 35
A TC PLAIN SPX W Primary transfer bias reference value Plain paper Front surface 5 - 35
18 18 20
B TC PLAIN DPX W Back surface 5 - 35
16 16 16
C TC PLAIN SPX N1 Front surface 5 - 35
22 22 24
D TC PLAIN DPX N1 Back surface 5 - 35
20 20 22
E TC PLAIN SPX N2 Front surface 5 - 35
26 26 28
F TC PLAIN DPX N2 Back surface 5 - 35
24 24 26
G TC HEAVY1 W Heavy paper 5 - 35
14 14 16
H TC HEAVY1 N1 5 - 35
18 18 20
I TC HEAVY1 N2 5 - 35
22 22 24
JTC OHP W OHP 5 - 35
10 10 10
K TC OHP N1 5 - 35
14 14 14
L TC OHP N2 5 - 35
14 14 14
M TC ENVELOPE W Envelope 5 - 35
14 14 16
N TC ENVELOPE N1 5 - 35
18 18 20
O TC ENVELOPE N2 5 - 35
22 22 24
PTC THIN W Thin paper 5 - 35
14 14 16
Q TC THIN N1 5 - 35
18 18 20
R TC THIN N2 5 - 35
22 22 24
S TC LABEL W Label paper 5 - 35
14 14 16
T TC LABEL N1 5 - 35
18 18 20
U TC LABEL N2 5 - 35
22 22 24
