Sharp MX-M266N

MX-M316N ADJUSTMENTS AND SETTINGS 5 – 6
3) Enter the adjustment value (specified value), and press [OK] key.
When [EXECUTE] key is pressed, the electric current entered in the procedure 3) is outputted for 30sec and the set value is saved.
When [EXECUTE] key is pressed again, the output is stopped.
By setting the default value (specified value), the specified output is provided.
ADJ 3 Image lead edge position,
image loss, void area, image
off-center, image magnification
ratio adjustment
(Automatic adjustment)
The following adjustment items can be executed automatically with
SIM50-28.
*ADJ 12
Print image position, image magnification ratio, void area, off-
center adjustment (Print engine) (Manual adjustment)
*ADJ 13
Scan image magnification ratio adjustment (Manual adjustment)
*ADJ 14
Scan image off-center adjustment (Manual adjustment)
*ADJ 15
Copy image position, image loss adjustment
(Manual adjustment)
Menu in SIM50-28 mode
3-A Print image off-center automatic
adjustment (Print engine)
(Each paper feed tray)
1) Enter the SIM50-28 mode.
2) Select [SETUP/PRINT ADJ] with the key.
3) Select [ALL] with the key.
CAUTION: By pressing [LEAD] or [OFFSET] key, the following
items can be executed individually.
* [LEAD]: Print image lead edge image position adjustment
* [OFFSET]: Print image off-center adjustment
When [ALL] is selected, both of the above two items are
executed simultaneously.
V TC TAB W Primary transfer bias reference value Tab paper 5 - 35 14 14 16
W TC TAB N1 5 - 35
18 18 20
X TC TAB N2 5 - 35
22 22 24
Y TC POSTCARD N2 Post card 5 - 35
26 26 24
Z TC ADSORPTION W 0 - 100
50 50 50
AA TC ADSORPTION N1 0 - 100
50 50 50
AB TC ADSORPTION N2 0 - 100
50 50 50
AC TC INTERVAL BIAS W 0 - 100
50 50 50
AD TC INTERVAL BIAS N1 0 - 100
50 50 50
AE TC INTERVAL BIAS N2 0 - 100
50 50 50
AF TC FRONTEDGE 0 - 100
60 60 60
AG TC BACKEND SPX 0 - 100
90 90 90
AH TC BACKEND DPX 0 - 100
80 80 80
Item/Display Content
Setting
range
Default value
26 31 35
Display/Item Content
OC ADJ Image loss off-center sub scanning direction image
magnification ratio adjustment (Document table mode)
SPF ADJ Image loss off-center sub scanning direction image
magnification ratio adjustment (RSPF mode)
SETUP/
PRINT ADJ
Print lead edge adjustment, image off-center (each paper
feed tray, duplex mode) adjustment
RESULT Adjustment result display
DATA Display of data used when an adjustment is executed
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
$872,0$*(326,7,21$'-8670(176(59,&(

2&$'- 63)$'-
6(78335,17$'- 5(68/7
'$7$



ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
$872,0$*(326,7,21$'-8670(176(59,&(

/($' 2))6(7
$//



1
: ‘15/Aug.
1
