H792x 3G/4G Router User Manual
5.7 System configuration
5.7.1 Overview
“System” can let you know the status of router, firmware upgrading and other
maintenance.
5.7.2 Local Log
Step 1 Log-on WEB GUI of H792x 3G/4G router.
Step 2 Click “System > Local Log” to open “Local Log” tab.
Figure 5-47 Local Log tab
Step 3 Select type of “Local Log” and then click “View” to see log.
Click “Clear” to clear the log info in the “Log Table”, and click “Export” to export log in
your local PC.
There are 3 types log:
Message: system log, to record the running log of router, usually for most of users.
Application: application program log, to record the Open or close of some application
programs.
Kernel: kernel log of router, usually for R&D engineers.
