H792x 3G/4G Router User Manual
192.168.8.1/24 and 192.168.9.1/24, the router QOS can control the ra te of these two subnets; If the
router's bandwidth is relati vely well-off, the router can adjust the bandwidth based on pri ority and
redundancy of two subnets, that is, the router meets the high priority redundancy bandwidth fi rs tly, then
meets the low priority subnet redundancy bandwidth.
---END
5.5.5 Dynamic Routing (Optional)
RIP configuration
RIP protocol (Routing Information Protocol) is the most widely IGP (Interior Gateway
Protocol) , it was designed for the same technology used in small networks, and therefore
adapt to most of the campus network and used in a continuous regional networks that the
rate change is not big, H792x 3G/4G Router supports RIP v2 protocol. For more complex
environments, generally do not use the RIP protocol.
Step 1 Log-on WEB GUI of H792x 3G/4G router.
Step 2 Click “Forward > RIP” to open “RIP” tab, as Figure 5-53.
Figure 5-34 RIP interface
Parameter Instruction as Table 5-26.
