H792x 3G/4G Router User Manual
Parameter
Details
Operation
PFS
To open or close PFS
Select from Dropdown List
Lifetime
IPSec SA key life time
Value area: 120～86400
Unit: second
Transport
Mode
Supports tunnel, transport
and auto.
Select from Dropdown List
Local Subnet
Set local subnet
No need to set for “transport”
mode,only for “auto” and
“tunnel”. Format: A.B.C.D/M
Remote
Subnet
To set local subnet
No need to set for “transport”
mode,only for “auto” and
“tunnel”. Format: A.B.C.D/M
Single click “save” icon to finish phase 2 setting.
3. “IPSec” parameter configuration
Figure 5-45 IPSec configuration tab
To configure “IPSec” parameters, and then click “Save”.
Table 5-30 IPSec Parameter instruction
Parameter
Details
Operation
Basic Settings
Select
To select which phase of
Select “IPSec”
