H792x 3G/4G Router User Manual
Parameter
Details
Operation
Local virtual IP
Virtual IP address of local tunnel
Format: interface type
A.B.C.D/M.
Peer virtual IP
Virtual IP address of peer tunnel
Format: interface type
A.B.C.D/M.
Interface type
To choose “interface” or “static
IP”
Select from Dropdown List.
Local Extern
interface
This parameter will need to be
set if “interface” is selected in
“interface type”. Choose any
connected interface as external
interface
Select from Dropdown List.
Local extern
IP
This parameter need to be set if
“static IP” is selected for
“interface type”. It is to set IP
address to external network
Format: interface type
A.B.C.D/M.
Peer extern IP
External interface IP of
counterpart network tunnel.
Usually a public IP address, also
can be a LAN IP
Format: interface type
A.B.C.D/M.
Step 6 Single click “save” icon to finish.
---END
5.6.4 IPSec configuration
Step 1 Log-on WEB GUI of H792x 3G/4G router.
Step 2 Click “VPN > IPSec” to open “IPSec” tab.
