H792x 3G/4G Router User Manual
Parameter
Details
Operation
recognize ICMP check fails
Retry
times/normal
interval
Check time interval and max check
failure times when link is OK, if
check failure times reaches the max
times, then “timeout action ” will
be executed, e.g. “modem reset”
Value area ：1～65535
Unit: second/time
Source
Interface
Router sends an ICMP detected
packet's source address
Dropdown List options

br0

modem
Timeout
action
An action when check failure times
reach max failure times. Can be
modem-reset, reboot, custom
Dropdown List options

modem-reset ： modem
redials

reboot：router reboots

custom ： customized
action
Run
commands
If “Timeout action” is “custom”, this
shall be comfigured. Commands are
BGO operation. It is not suggested
to use, if need, pls contact our
technical engineers
WORD type, max 64 bytes
5. Single click “save” to finish a ICMP check rule.
If ICMP is normal, ICMP packet is sent at “normal interval”. When abnormal , packet will be sent
continuousl y at “failed interval ”. If “destination address” cannot be linked and checking times rea ch
“retry ti mes”, “destination backup” will be checked. if “destination address ” can be linked in checking
“destination backup”, “destination address ” will be checked again. If “destination backup” cannot be
linked and checking times reach “retry times”, “Timeout a ction” will be executed.

Modify

Delete

Enable
If al ready enabled, the button “EN” is gray.

Disable
If al ready disabled, the button “DIS” is gra y

Refresh
Click “refresh” to refresh the page.
