H792x 3G/4G Router User Manual
Parameter
Details
Operation
Task type

Triggered action includes
modem-up, modem-down,
reboot.
Dropdown List options

modem-down

modem-up

reboot
Basic setting
Wake up
method
To configure actions triggered, it
supports phone and data. If
choose phone, please be sure
that the SIM card has opened
voice or SMS service. Usually
recommend voice wakeup with
high efficiency and don’t need
SMS charge.
Dropdown List options

phone/data

phone
Offline
method
Support “timeout” and “idle”.
“timeout” means router will get
offline once time reaches the
configured time commencing
from online time. “idle” means if
idle (no data transmission) time
is as long as the configured time,
the router will get offline.
Dropdown List options

timeout

idle
Online time
Online time of router, for “idle”,
online time will recalculated if
there is data transmission.
Value area ：0～86400
Unit: second
Data trigger
Configured as wakeup by data.
When router receives data from
external network, the modem
will be triggered to be online,
LAN data and broadcast data
will not trigger actions. If
configured as “phone&data”,
either phone or data can trigger
actions
Dropdown List options

modem-up
Step 4 click “ADD” to add a new wake up rule.
After add a new rule, the rule will be shown on the bottom, click “Del” to delete the rule.
