Shimadzu GC-2014 Series User Manual

Table of Contents
CHAPTER 7 TROUBLESHOOTING........................................99
7.1 Gas and Pressure/Flow-Rate Settings ...................................... 99
7.1.1 Precautions for Flow-Rate Control Settings (CAR) ................................. 99
7.1.1.1 When the control mode is "SPLIT" or "SPLITLESS": ............................... 99
7.1.1.2 When the control mode is "TOTAL FLOW" and the injection mode is
"DIRECT": ................................................................................................102
7.1.1.3 When the control mode is "PRESS" or "LINEAR VELOCITY" and the
injection mode is "DIRECT": ....................................................................102
7.1.1.4 Precautions for Flow-Rate Control Settings (DetAPC) ............................104
7.2 Temperature Control.................................................................105
7.3 Detector....................................................................................105
7.3.1 FID ......................................................................................................... 105
7.3.2 FPD........................................................................................................ 106
7.3.3 FTD........................................................................................................ 106
7.4 Chromatogram and Data..........................................................106
7.5 Other Problems ........................................................................107
CHAPTER 8 SERVICE WINDOW..........................................109
8.1 Flow Adjust (CAR) ....................................................................110
8.2 Flow Adjust (DetAPC)............................................................... 111
8.3 Flow Adjust (AUX APC) ............................................................ 111
8.4 Temp. Sensor Use Time ...........................................................112
8.5 Mode ........................................................................................112
8.6 Serial Number ..........................................................................113
8.6.1 Main Body Serial Number.......................................................................113
8.6.2 Unit Serial Numbers ...............................................................................114
8.7 Maintenance Log......................................................................114
8.8 Fan & LCD Use Time ...............................................................115
8.9 Init. for Shipment ......................................................................115
CHAPTER 9 APPENDIX........................................................117
GC-2014 Service Manual
3

Shimadzu GC-2014 Series Specifications

General

Type	Gas Chromatograph
Detector Options	FID, TCD, ECD, FPD, FTD
Display	LCD
Injection Ports	Up to 3
Column Options	Capillary, Packed
Data System	GCsolution software
Weight	Approx. 45 kg
Number of Detectors	Up to 4 detectors
Injection Port	Split/Splitless
Power Requirements	100-240V AC, 50/60Hz
