Appendix
11-6 MORPHEUS MRI
Automatic compensation
of atmospheric pressure
on measured pressure
Present (max. 5000 mt)
Respiratory parameters
default setting
Present (newborn, children, adult)
Flow generation Electronic system
Gas feeding Medical compressed air or Oxygen with pressure included between 280 kPa and
600 kPa (2,8 – 6 bar)
Autotest Primary test: at anaesthesia unit’s start-up, a control test of medical gas supply,
sensors operation, back-up battery, oxygen cell, integrity of the alarm audible
indicator, led on CPU board. This test takes around 15 seconds.
Subtest: this subtest permits to verify the dead space and losses or to perform
the oxygen cell calibration.
Ventilation modalities
MANUAL, VC-VAC, PCV-APCV
Breathing rate
From 5 to 90 bpm (step 1 bpm)
I:E Ratio
1:4 ÷ 4:1
Inspiratory time
From 0.2 to 5 sec.
Tidal Volume
From 50 to 1500 ml
Minute Volume
From 1 ÷ 30 liters
PEEP OFF, 3 ÷ 30 cmH
2
O
Inspiratory Flow
From 1 ÷ 80 L/min.
Oximeter
Minimum resolution 1% / Automatic calibration procedure
High pressure limit From 10 to 80 cmH
2
O
Bronchomanometer Electronic: from -10 ÷ 80 cmH
2
O
Flow trigger
From OFF, 1 to 15 L/min (step 1 L/min)
Pressure trigger From OFF, -1 to -9 cmH
2
O under the PEEP level
Safety
Electronic and mechanical limit of airways pressure / Self-diagnosis system
Flow sensor
Pressure relief single patient sensor
Alarms Fan Failure, Air Failure, High / Low Airways Pressure, Low O
2
concentration, O
2
cell into operation or not present, Apnoea, Expired Tidal Volume, Power Failure,
Low Battery.
Measured parameters PAW, FiO
2
, VM, Tinsp, RATE, Vte
