3 PRODUCT DESCRIPTION
34
OPERATING INSTRUCTIONS | AFS60/AFM60 PROFINET 8015078/145N/2019-05-24 | SICK STEGMANN
Subject to change without notice
Index
Su b index
Description
Access
5)
Data type
Data values
.12
Bit 13
1 … 255
.13
Bit 14
1 … 255
.14
Bit 15
1 … 255
1,005
Speed calculation
R
Array [0 … 15] UINT-16
.0
Mode for the speed calculation
0 Not active
1 Active
.1
Speed measuring unit
0 steps/s
1 steps/100ms
2 steps/10ms
3 rpm
4 rps
.2
T1 – Refresh time in ms
AFS60 = 2
AFM60 = 1 … 50
.3
T2 – Integration time dependent of the
refresh time
The speed is calculated from the
average of several measurements. The
integration value T2 defines the number
of values from which the average is
calculated. The refresh time T1 defines
the time between the individual
measurements.
Example:
If T1 = 2 ms and T2 = 200, then the
speed is calculated from the last 0.4 s.
1 … 200
1,006
Limits of the operating temperature
allowed
R/W
Array [0 … 1] UINT-16
.0
Defines the lower limit for the operating
temperature allowed in °C
–40
+80
.1
Defines the upper limit for the operating
temperature allowed in °C
–20
+120
1,007
Limit of the supply voltage allowed
R/W
Array [0 … 1] UINT-16
.0
Defines the lower limit for the supply
voltage allowed in mV
9,000
24,000
.1
Defines the upper limit for the supply
voltage allowed in mV
10,000
30,000
