SICK AFS60 PROFINET User Manual

COMMISSIONING 4
8015078/145N/2019-05 -24 | SICK STEGMANN OPERATING INSTRUCTIONS | AFS60/AFM60 PROFINET
43
Subject to change without notice
Pin
Signal
Wire color
7)
Function
1
VS
Brown
Supply voltage 10 … 30 V DC
2
–
White
Do not use
3
GND
Blue
0 V DC (Ground)
4
–
Black
Do not use
Table 38: Pin assignment for the connection of the voltage supply
NOTE
Pin 2 and 4 are not allowed to be assigned, otherwise irreparable damage could be
caused to the AFS60/AFM60 PROFINET.
Pin
Signal
Wire color
7)
Function
1
TxD+
Yellow
Ethernet
2
RxD+
White
Ethernet
3
TxD–
Orange
Ethernet
4
RxD–
Blue
Ethernet
Table 39: Pin assignment for the connections port 1 and port 2
NOTE
 Connect the screen to the encoder’s housing!
 Pay attention to the maximum cable lengths.
 Mount all cables with strain relief.
7
)
On the usage of pre-wired cables.
