Operating Instructions Chapter 11
C4000 Select
8012247/RI61/2007-11-30 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 57
Technical specifications
Minimum Typical Maximum
Extended I/O input type
(
according to EN 61131@2)
Type 3
2
2)
. Dual-channel, PNP semiconductor,
e
xternally short-circuit protected, externally cross-
circuit monitored e.g. from an S3000 safety laser
scanner or another C4000 Select receiver
I
nput voltage
2
3)
HIGH
1
1 V DC 24 V DC 30 V DC
I
nput current HIGH 3 mA 5 mA 7 mA
Input voltage LOW –30 V DC 0 V DC 5 V DC
Input current LOW –1.2 mA 0 mA 2.5 mA
24)
Input capacitance 5 nF
Input test pulse filtering
25)
Test pulse rate 160/s
Test pulse gap 700 µs
Safe input discrepancy time 20 ms
Operating data
System connection
M12× 5, male
Maximum cable length
26)
30 m
Extension connection M12× 5, female
Maximum cable length
10 m
Ambient operating temperature 0°C +55°C
Air humidity (non-concensing) 15%95%
Storage temperature –25°C +70°C (24 h)
Enclosure rating
27)
IP 65
Housing cross-section 52 mm × 55.5 mm
Vibration resistance 5 g, 10-55 Hz acc. to IEC 60068@2@6
Shock resistance 10 g, 16 ms acc. to IEC 60068@2@29
Environmental data, materials
Housing Aluminium alloy ALMGSI 0.5 (powder coated)
Front screen Polycarbonate, scratch-resistant coating
End caps Polyamide 6.6 CF30
Packaging Corrugated cardboard with Instapak® inlays
Circuit boards Glass-fibre reinforced epoxy resin with flame
retarding agent TBBPA
22)
The “Type” designation listed here describes the kind of inputs that may be connected to the extended I/O
safety input connection. This particular designation is not related to the “Type” designation defined by
IEC 61496@1, @2.
23)
As per IEC 61131@2, type 3.
24)
Maximum leakage current allowed, even in the event of an error or fault condition.
25)
These values indicate the filtering capability of the C4000 Select in evaluating OSSD signals at the extended
I/O safety capable inputs without generating a stop condition based on the test pulse occurrence.
26)
Depending on load, power supply and wire cross-section. The technical specifications must be observed; e.g.
supply voltage and permissible line resistance.
27)
In order to satisfy enclosure rating, the cover plate over the DIP switches must be secured correctly. Further,
system and extended I/O cables must be rated IP 65 or better and must also be attached to the C4000 Select
correctly. You must use protective caps that are suitable for IP 65 enclosure rating for any unused connectors.
