Specifications
DUSTHUNTER T · Operating Instructions · 8012428 V 2.0 · © SICK MAIHAK GmbH Germany 109
Dust concentration measuring range
The limits for the smallest/largest measuring range depend on the extinction measuring
range, active measuring path and optical particle characteristics. Therefore exact range
limits cannot be specified here. The following charts can be used to estimate the ranges
used. These have been determined based on SICK's many years of experience and are
valid assuming constant particle size and characteristics.
Power Supply
Control unit Power supply
Power consumption:
85...250 V AC, 47...63 Hz; opt. 24 V DC ± 2 V
Max. 15 W without purge air supply
Max. 70 W with purge air supply
Sender/receiver unit Power supply:
Power consumption:
24 V from control unit
Max. 15 W
Optional external purge air unit
(with blower 2BH13)
Power supply:
Rated current:
Motor rating:
200 ... 240 V/345...415 V at 50 Hz;
220...275 V/380...480 V at 60 Hz
2.6 A/Y 1.5 A
0.37 kW at 50 Hz; 0.45 kW at 60 Hz
Dimensions (W x H x D)
Sender/receiver unit 395 mm x 250 mm x 212 mm
420 mm x 250 mm x 212 mm
DHT-T00
DHT-T10, DHT-T21
Reflector 395 mm x 250 mm x 212 mm
420 mm x 268 mm x 265 mm
DHT-R00, DHT-R01, DHT-R02
DHT-R10, DHT-R11, DHT-R12
Control unit 300 mm x 400 mm x 220 mm
200 mm x 200 mm x 130 mm
MCU-P
MCU-N
Optional external purge air unit 550 mm x 550 mm x 258 mm; with weatherproof cover 605 mm x 550 mm x 350 mm
Weight
Sender/receiver unit 5 kg
6.5 kg
10 kg
DHT-T00
DHT-T10
DHT-T21
Reflector 3 kg
5 kg
DHT-R00, DHT-R01, DHT-R02
DHT-R10, DHT-R11, DHT-R12
Control unit 13.5 kg
3.7 kg
MCU-P
MCU-N
Optional external purge air unit 14 kg
Misc.
Degree of protection IP 66
IP 54
Sender/receiver unit, reflector, control unit
Optional external purge air unit
Connection cable length 5 m, 10 m Other lengths on request
Purge air hose length 5 m, 10 m Other lengths on request
Sender LED White light, wavelength between 450 nm and 700 nm
Purge air feed volume Max. 20 m³/h
Max. 63 m³/h
MCU control unit
Optional external purge air unit
