Operating Instructions GM35
Probe Model
Maintenance
8009389/07-2006 © SICK MAIHAK GmbH • Germany · All rights reserved 79
Fig. 42 Installing the filter box
‡ Insert the driving rod for filter selection completely; thereby secure that the filter is swung
out.
Filter box plate
Recess for humidity
sensor
Filter box
GM35 SR unit
