Temperature Measurement
Transmitters for rail mounting
SITRANS TR300
two-wire system, universal, HART
3/41
Siemens FI 01 · 2012
3
■ Selection and Ordering data Order No.
D) Subject to export regulations AL: N, ECCN: EAR99H.
Supply units see Chap. 8 "Supplementary Components".
Ordering example 1:
7NG3033-0JN00-Z Y01+Y17+Y29+U03
Y01: 0...100 C
Y17: TICA123
Y29: TICA123
Ordering example 2:
7NG3033-0JN00-Z Y01+Y17+Y23+Y29+U25+U40
Y01: 0...600 C
Y17: TICA123
Y23: TICA123HEAT
Y29: TICA123HEAT
Factory setting:
• Pt100 (IEC 751) with 3-wire circuit
• Measuring range: 0 ... 100 °C (32 ... 212 °F)
• Error signal in the event of sensor breakage: 22.8 mA
• Sensor offset: 0 °C (0 °F)
• Damping 0.0 s
Temperature transmitter SITRANS TR300
For mounting on a standard DIN rail, two-wire
system, 4 … 20 mA, HART, with electrical iso-
lation, with documentation on CD
• Without explosion protection }
D)
7NG3033-0JN00
• With explosion protection to ATEX }
D)
7NG3033-1JN00
Further designs Order code
Please add "-Z" to Order No. with and specify
Order codes(s).
With test protocol (5 measuring points) C11
Functional safety SIL2 C20
Functional safety SIL2/3 C23
Customer-specific programming
Add "-Z" to Order No. and specify Order code(s)
Customer specific programming, specify
measuring range in plain text
Y01
1)
Measuring point no. (TAG), max. 8 characters Y17
1)
Measuring point descriptor, max. 16 charac-
ters
Y23
1)
Measuring point message, max. 32 characters Y24
1)
Text on front label, max. 16 characters Y29
1)2)
Pt100 (IEC) 2-wire, R
L
= 0 Ω U02
1)
Pt100 (IEC) 3-wire U03
1)
Pt100 (IEC) 4-wire U04
1)
Thermocouple type B U20
1)
Thermocouple type C (W5) U21
1)
Thermocouple type D (W3) U22
1)
Thermocouple type E U23
1)
Thermocouple type J U24
1)
Thermocouple type K U25
1)
Thermocouple type L U26
1)
Thermocouple type N U27
1)
Thermocouple type R U28
1)
Thermocouple type S U29
1)
Thermocouple type T U30
1)
Thermocouple type U U31
1)
With TC: CJC internal U40
1)
With TC: CJC external (Pt100, 3-wire) U41
1)
With TC: CJC external with fixed value, specify
in plain text
Y50
1)
Special differing customer-specific program-
ming, specify in plain text
Y09
1)3)
Fail-safe value 3.6 mA (instead of 22.8 mA) U36
1)
Accessories Order No.
CD for measuring instruments for
temperature
} A5E00364512
With documentation in German, English,
French, Spanish, Italian, Portuguese and
SIPROM T parameterization software
HART modem
• With RS 232 connection }
D)
7MF4997-1DA
• With USB connection }
D)
7MF4997-1DB
Simatic PDM operating software See Section 9
} Available ex stock
1)
Y01 is madatory for any customer-specific programming. Additionally
with Y01 the data of the customer-specific programming are printed
on the product.
2)
Text on front label not stored inside transmitter.
3)
If needed, here you can mention settings, which cannot be specified
with existing order codes.
© Siemens AG 2011
