6 Other Functions
33
6.1.1 Setting measuring range
Pressing the [MEASURE RANGE] button in the MENU 1/5 (OPERATION menu) screen
displays the MEAS. RANGE screen.
In this screen, the measure range can be confirmed.
Fig. 27 MEAS. RANGE screen
Press the range button of the component to be set.
Fig. 28 NOx RANGE screen
Press the button of the component to be set as a measurement component, and execute
the setting.
Setting item Description
RANGE 1 Selects RANGE 1.
RANGE 2 Selects RANGE 2.
AUTO
Allows automatic range switching.
According to the measurement concentration, automatically switches RANGE 1
and RANGE 2.
EXT
Allows external range switching.
By external contact input, RANGE 1 and RANGE 2 is switched.
Range 1
Range 2
