PRODUCT DESCRIPTION 2
2.2.4.2 Versions
● Control unit MCU-N without purge air supply
Fig. 11: Control unit MCU-N with options
DISPLAYMODUL
relay 3 relay 4 relay 5
BUS
Ter m
Ter m
relay 1 relay 2
com nc. no.com nc. no. com nc. no.com nc. no.com nc. no.
Reset


 


Display module (option)  I/O module (option)

Processor board  Display module (option)

Interface module (option)
