7 Maintenance
69
7.3.9 Replacing the air filter
1. Turn OFF the pump 1 and pump 2 switches.
2. Disconnect the tube connected to the cap.
3. Remove the cap and take out the air filter.
4. Perform cleaning inside the pot.
5. Replace the air filter and assemble it by the reversed procedure.
Fig. 61 Replacing the air filter
Cap
Air filter
Pot
Fixing plate
(9057005000)
