4 START-UP AND PARAMETER SETTINGS
Group Input window Parameter Remark
Device
identification
Mounting
location
Name of the measuring
location
Assignment of measuring system to the respective
measuring location
Flange - flange Flange distance measured
on the duct
For registration (e.g. repeated reference setting on a
dust-free path)
Opt. measuring
distance
Active measuring path Input required for calculation of relative opacity
Chimney
opening
Chimney diameter at top
end
Correction
factor
Value Adaption of relative opacity to geometric dimensions of
channel
Concentration
calibration
coeffecients = f
(extinction)
cc2 Quadratic coefficient Input of regression coefficients determined on
extinction basis for measurement of the dust
concentration in mg/m³ (see “Calibration for dust
concentration measurement”, page 80).
cc1 Linear coefficient
cc0 Absolute coefficient
RK_Gruppe_LED_
Span2
Span2
transmission
Activated The second control value is
compared with the reference
value during the function check.
Activation and input
of reference value
possible only when
the “EPA Conformity”
is activated
Deactivated The second control value is not
used.
Reference value Transmission value in % Input of a second control value
for the function check (see
“Function check”, page 13)
Limit
contamination
and average
Limit
contamination
Value in % Determination of a limit value, optionally 40% (default
value), 20%, 10%, 6%, 4%
When checkbox “EPA Conformity” is activated, limit
value 4% is firmly assigned.
Limit warning 75% of limit value Automatic determination depending on the entered
limit value
Average active Activated When the checkbox is activated, an average is created
from the values measured in the determined average
interval.
Deactivated
Average Interval Interval time
1/2/3/4/5/6min
Selection of interval time (6 min for use according to
EPA standard)
Selection
Measure Value
Measured variable Selection of measured variable whose values are to be
averaged
EPA Conformity EPA-mode
active
Activated For use according to EPA standard
Deactivated No use according to EPA standard
