4 START-UP AND PARAMETER SETTINGS
Measured value assignment
Window Entry field Significance
Common Display
Settings
Display language Language version shown on the LC-Display
Display Unit System Unit of measurement system used in displays
Overview Screen
Settings
Bars 1 to 8 Number of measured value for the first measured
value bar in the graphic display
Value Measured value index for the respective measured
value bar
Use AO scaling When activated, the measured value bar is scaled to
the associated analog output. If not activated, define
the limit values separately
Range low Values for separate scaling of the measured value bar
independent of the analog output
Range high
Security settings
Authorized operator
Password input for the Display menu operating level
“Authorized Operator”
Default: 1234
Idle time
Time until user level “Authorized Operator” is automat-
ically switched off again.
MCU measured value Sender/receiver unit measured value
Value 1 Opacity
Value 2 Not used
Value 3 Concentration a.c.
Value 4 Extinction
Value 5 Rel. opacity
Value 6 Transmission
Value 7 Not used
Value 8 Not used
MCU Value 2 Concentration s.c.
