9 TECHNICAL DATA
106
8011325/18IM/2020-07-02|SICK
OPERATING INSTRUCTIONS | ICR880/890
Subject to change without notice
9.7 Dimensional drawing of the deflector mirror
Fig. 69: Dimensional drawing of the deflector mirror
