6.2.8 Setting the camera system to online
Establish a connection between the SOPAS project and the camera system. This
connection will make it possible to subsequently read camera system parameters
and configuration data in the SOPAS project or write these to the camera system from
SOPAS-ET.
During the initial commissioning, the standard parameters saved on the camera system
at the factory are transferred to the SOPAS project and then adapted to the requirements
of the relevant application there.
1. Click the Offline button in the tile.
Alternatively, you can open the context menu and select the Go online command there.
2. You are prompted to synchronize the camera system's device data with the device data
of the SOPAS project.
3. As the standard parameters are currently only available in the camera system and are
not yet in the SOPAS project, click the Read parameters option.
The connection between the camera system and the configuration PC is now established.
The standard parameters are transferred from the camera system into the SOPAS project.
Online appears in the tile. The LED lights up green.
