9.2 Data sheet for the ICI890-0x / ICI890-1x illumination unit
Type
ICI890-00xxx
ICI890-10xxx
ICI890-01xxx
ICI890-11xxx
ICI890-02xxx
ICI890-12xxx
Function
LED illumination
Light color/wavelength
ICI890-0x: red, λ = 630 nm
ICI890-1x: blue-white, λ = 470 nm
LED risk group
Variants with red LEDs
Risk group RG 1 (low risk) according to IEC 62471-1: 2006-07 / EN 62471-1: 2008-09.
Irradiance: L
B
< 10 x 10
3
W/(m²sr)
within 100 s (RG 1),
at distances ≥ 200 mm.
L
R
< 2.8 x 10
5
W/(m²)
within 10 s (RG 0),
at distances ≥ 200 mm.
Variants with blue-white LEDs
Risk group RG 2 (moderate risk) acc. to IEC 62471-1: 2006-07 / EN 62471-1: 2008-09
due to blue light hazard.
Irradiance: L
B
< 4 x 10
6
W/(m²sr)
within 0.25 s (RG 2),
at distances ≥ 200 mm.
L
R
< 2.3 E6 W/(m²sr)
within 0.25 s (RG 2),
at distances ≥ 200 mm.
Risk RG 1 (low risk) corresponding to L
B
< 10 x 10
3
W/(m²sr) within 100 s at distances
> 10 m. This distance is only necessary in the range of maximum brightness in the direct
illumination field.
Switch-on time
Depending on reading pulse, minimum switch-off time 3 s
MTBF of the device
> 80,000 h
MTTR of the device
2)
< 10 min
Profile length
1,100 mm
900 mm
750 mm
Number of LED modules
10
8
4
Electrical connections
1 x male connector, M12, 8-pin (control data interface for the camera)
1 x Harting HanQ8 plug connector, 8-pin (input for DC 24 V voltage supply)
Supply voltage
DC 24 V ± 20%
Power consumption
ICI890-00000, -01000, -01100, 02100:
Typ. 160 W
3)
, max. 400 W
Typ. 130 W
3)
, max.
320 W
Typ. 80 W
3)
, max. 170 W
ICI890-10000, -11000, -11100, 12100:
Typ. 260 W
3)
, max. 400 W
Typ. 210 W
3)
, max. 320
W
Typ. 130 W
3)
, max. 170 W
Housing/front screen
Aluminum die cast/plastic (glass for camera view)
Outside of the housing, no materials using silicon
Enclosure rating
IP 64 according to EN 60529: 1991-10; A1: 2000, A2:2013, fan IP 54
Protection class
Class III in accordance with EN 61140: 2016
EMC test
In accordance with EN 61000-6-2: 2005, EN 61000-6-4: 2007
Vibration test
In accordance with IEC 60068-2-6: 2007
Shock test
In accordance with IEC 68-2-27: 2008-02, equivalent to EN 60068-2-27: 2009
Dimensions
See 9.6 Dimensional drawing of the ICR880/890 camera systems
Weight
Approx. 23.5 kg
Approx. 19 kg
Approx. 15 kg
